Easy of Assembly & Service

The easy to remove shroud ensures easy access to the belt-drive system for maintenance and servicing without removing the pedals or crank.

Innovation for Superior Riding Comfort

Over-molded handle bars add comfort and durability while offering heart rate contacts and three ergonomic riding positions: upright, cruising and road. The simple seat adjustment allows the user to change the position of the seat with one hand, either on or off the bike.

P82 Touch Screen Console

The P82 touch screen console offers a brilliant 15" screen that's ergonomically positioned to deliver crystal clear entertainment viewing for exercisers in motion.

  EQUIPMENT FEATURES

Covers: Covers are attached with minimal hardware and can be removed without taking off the pedals or cranks.

Cable Management: Optional

Accessory Holder(s): Yes

Transport Wheels: Integrated

Frame: Two-step powder-coating process applies rust-resistant undercoat and cosmetic topcoat to steel frame.

Bearings: The bottom bracket assembly uses a hardened steel shaft with deep-groove sealed precision ball bearings designed for smooth operation and exceptional service life.

Seat: Ergonomic saddle design with comfort groove. 10.5 inches (27 cm) width quickly tapers to a narrow nose for improved riding comfort. Optional universal seat post allows easy installation of different saddle types.

Handlebars: A new over-molded handlebar design offers the user three comfortable riding positions-upright, cruising, and road. In the road position, the ergonomic-shaped handlebars position the wrists in a natural, neutral position. The wide width of the handlebars provide stability and comfort along the entire forearm. The overall width of the handlebars is similar to indoor cycling bikes, which is narrower than most stationary bikes. This places the user in better ergonomic position with the forearms more directly under the shoulders. In the cruising position, the wide handlebar is more comfortable on the user's hands. Touch heart rate is integrated in the upright and road-race positions.

Pedals: For double the convenience, dual-sided pedals allow the rider to use the pedals with or without the integrated pedal strap. The extra wide pedal comfortably accommodates feet of all sizes, which allows proper pedaling form with the foot directly over the user's knee.

Biomechanics: To achieve proper pedaling biomechanics, the seat post and seat post offset from the crank is key to aide in efficient pedaling and reduced shear force on the knee. The seat post angle is 74 degrees with a 5 inch (13 cm) offset from the crank axle. This places the forward knee directly over the ball of the foot (or pedal spindle) when the pedals are in a horizontal position.

  RESISTANCE SYSTEM

Minimum Watts: 18 watts (level 1 at 20 RPM)

Maximum Watts: 750 watts (level 25 at 150 RPM)

Resistance Level: 25

3-Piece Crank: 3-piece crank tightens positively, reducing the need for periodic adjustments. The 170 mm crank arm accepts any standard road or mountain bike pedal.

Drive System: The two-stage drive system yields a smooth, comfortable, quiet operation with a lower start-up resistance and more consistent resistance progression than single-stage drive systems.

3-Phase Generator:3-phase generator / eddy current resistance system requires no backup battery in order to efficiently power the bike.

Belt Drive: Belt drive for smoother, quieter operation and reduced maintenance.

  HEART RATE MONITORING

Touch: Yes. Touch heart rate sensors conveniently located on the handlebars in both the upright and road positions.

Telemetry: Yes. Integrated telemetry heart rate reads heart rate from a user's heart rate chest strap.

SmartRate®: No

  NETWORK CAPABILITIES

Diagnostics: Ability to set club parameters, e.g. limit exercise time, set default language and pause time.

CSAFE Ready: No

FitLinxx Compatible: No

Wireless: Yes

Preva® Network Capable: Optional

  POWER REQUIREMENTS

Equipment: Powered

International 240 VAC: Applicable country-specific power cord

U.S. & Canada 240 VAC: N/A

U.S. & Canada 120 VAC: 120V/15A circuit with 5-15P NEMA receptacle

Personal Viewing Screen (PVS): Powered

  EQUIPMENT SPECIFICATIONS

Maximum User Weight: 350 lbs / 159 kg

Standard Frame Colours: Gloss Metallic Silver / Black Pearl

  REGULATORY

FCC: FCC

ETL: ETL

CE: CE

EN957: EN957 / ASTM

  INTEGRATED ENTERTAINMENT OPTIONS

Reading Rack: Optional

Personal Viewing System (PVS): Integrated

Personal Viewing Screen (PVS) (Specification): 15in. LCD Capacitive Touch Screen

iPod® / iPhone® Compatible: Integrated

Weight: 169 lbs / (76.65 Kilograms)

Dimensions: 48" L x 21" W x 62" H
